ZKR Dewatering Vibrating Screen

CAPACITY : 5-1080t/h

MAX FEEDING SIZE : 250mm

APPLICATION : Mining, metallurgy, construction, highway, railroad, and water conservancy, etc.

RAW MATERIALS :River stone, gravel, granite, basalt, minerals, quartz, diabase, etc.

iron ore
copper ore
artificial sand
limestone

Chat Online Get Price List

60s online
customer service

2 days customize
solutions

Factory
visiting anytime

1-10 days dispatch
the goods

One week
of installation

2 days of
training

365 days
after-sales online

Project tracking
regularly

2 days provide
maintenance plan

Pre-sale service

Sales service

After-sales service

Tip1: The specific time arrangement depends on the actual situation. Tip2: Free airport transfer and hotel accommodation.

Introduce

ZKR series high frequency linear screen (also into dehydration screen) is a vibrating dehydration screen introduced by our company and developed by absorbing foreign technology, widely used in building materials, metallurgy, electric power, coal, light work and other industries, suitable for small granularity of materials, such as fine sand, tailings, tailings of dehydration dry discharge, with large processing capacity, dehydration net, low water content of finished materials after dehydration advantages.

Features

1. Strong exciting force provided by eccentric block;

2. High strength bolts without welding;

3. Simple structure and convenient maintenance;

4. Flexible connection ensured by tire couplings and smooth operation;

5. High screening efficiency, large capacity and long service life;

PRODUCT DATA:

Model	Mesh					Max Feed Size	Capacity	Motor Power	Weight
Model	Mesh Layer (layer)	Mesh Size WxL （mm）	Area (m2)	aperture (mm)	Material	(mm)	（t/h）	(kw)	(t)
ZKR1022	1	1000x2200	2.25	0.25-50	Woven, Slit, Stamping, Rubber, Polyurethane Mesh	250	4.5-90	3×2	2.215
ZKR1230		1200x3000	3.6	0.25-50			7.2-144	4×2	2.693
ZKR1237		1200x3700	4.5	0.25-50			9-180	5.5×2	3.118
ZKR1437		1400x3700	5.25	0.25-50			12-250	5.5×2	3.21
ZKR1445		1400x4500	6.3	0.25-50			12.6-252	7.5×2	4.04
ZKR1637		1600x3700	6	0.25-50			12-240	5.5×2	3.552
ZKR1645		1600x4500	7.32	0.25-50			95-280	11×2	4.572
ZKR1837		1800x3700	6.75	0.25-50			90-270	11×2	4.995
ZKR1845		1800x4500	8.1	0.25-50			16.2-234	11×2	5.436
ZKR1852		1800x5200	9.45	0.25-50			18.9-378	11×2	5.9
ZKR2045		2000x4500	9	0.25-50			16.2-324	11×2	5.969
ZKR2052		2000x5200	10.5	0.25-50			21-420	11×2	6.472
ZKR2060		2000x6000	12	0.25-50			24-480	15×2	7.558
ZKR2445		2400x4500	10.8	0.25-50			21.6-432	15×2	7.439
ZKR2452		2400x5200	12.6	0.25-50			25.2-504	15×2	8.216
ZKR2460		2400x6000	14.4	0.25-50			28.8-576	15×2	9.235
ZKR3045		3000x4500	13.5	0.25-50			27-540	15×2	9.859
ZKR3052		3000x5200	15.75	0.25-50			31.4-628	22×2	9.958
ZKR3060		3000x6000	18	0.25-50			17.5-525	22×2	11.062
ZKR3645		3600x4500	16.2	0.25-50			37.8-756	22×2	12.289
ZKR3652		3600x5200	18.9	0.25-50			43.2-864	22×2	13.409
ZKR3660		3600x6000	21.6	0.25-50			43.2-864	22×2	14.39
ZKR3675		3600x7500	27	0.25-50			54-1080	30×2	17.1
2ZKR1022	2	1000x2200	2.25	0.25-50			4.5-90	4×2	3.018
2ZKR1230		1200x3000	3.6	0.25-50			7.2-144	5.5×2	3.74
2ZKR1237		1200x3700	4.5	0.25-50			9-180	7.5×2	4.46
2ZKR1437		1400x3700	5.25	0.25-50			12-250	7.5×2	5.042
2ZKR1445		1400x4500	6.3	0.25-50			12.6-252	15×2	6.883
2ZKR1637		1600x3700	6	0.25-50			12-240	15×2	6.919
2ZKR1645		1600x4500	7.32	0.25-50			95-280	15×2	8.654
2ZKR1837		1800x3700	6.75	0.25-50			90-270	15×2	7.951
2ZKR1845		1800x4500	8.1	0.25-50			16.2-234	15×2	8.116
2ZKR1852		1800x5200	9.45	0.25-50			18.9-378	15×2	9.061
2ZKR2045		2000x4500	9	0.25-50			16.2-324	15×2	9.113
2ZKR2052		2000x5200	10.5	0.25-50			21-420	22×2	10.128
2ZKR2060		2000x6000	12	0.25-50			24-480	22×2	10.875
2ZKR2445		2400x4500	10.8	0.25-50			21.6-432	22×2	11.008
2ZKR2452		2400x5200	12.6	0.25-50			25.2-504	22×2	12.757
2ZKR2460		2400x6000	14.4	0.25-50			28.8-576	22×2	13.56
2ZKR3045		3000x4500	13.5	0.25-50			27-540	30×2	15.472
2ZKR3052		3000x5200	15.75	0.25-50			31.4-628	37×2	16.942
2ZKR3060		3000x6000	18	0.25-50			17.5-525	37×2	18.253
2ZKR3645		3600x4500	16.2	0.25-50			37.8-756	45×2	21.042
2ZKR3652		3600x5200	18.9	0.25-50			43.2-846	45×2	24.04
2ZKR3660		3600*6000	21.6	0.25-50			43.2-846	45×2	25.4

Note:
1. The above capacity in the table is the parameter corresponding to crush the stone with a loose density of 1.6t/m3;
2. According to the nature of the material, the feeding method is different, the processing capacity will be changed;
